Bad Boy MZ User Manual

SECTION 9: MOVING INOPERABLE MOWER
9.1 If it is necessary to move mower when the engine is inoperable, the hydraulic drive pumps
are equipped with bypass valves. Before moving the mower, turn the bypass valves counter-
clockwise one-half to one revolution. The valve stems on each pump are located near the top
and are identified as a hex stud.
9.2 Do not tow machine. Move it by hand or use a winch to load on a trailer for transporting.
9.3 ATTENTION: RETURN BYPASS VALVES TO OPERATING POSITION BEFORE RUNNING
MOWER FOLLOWING REPAIRS.
9.4 ZT Models are equipped with two neutral engage/disengage arms, located at the rear of
the mower protruding from the frame and under the muffler. By pulling the arms out the
mower can be put in a neutral position. Return the arms to the “forward position for normal
operation.
9.5 Your Bad Boy Mower Weighs: MZ SERIES: 585—602 lbs
*** Weights fluctuate with the addition of accessories.
9.6 As you can see by the weights of the machines, you shouldn’t ever try to push or pull a Bad
Boy Mower by hand. This could cause serious bodily injury.
9.7 Hopefully, you’ll never need to use this section of the manual. However, if you do, use
extreme caution when moving machine!
PAGE 12

Bad Boy MZ Specifications

General

Deck Material	Steel
Cutting Width	54 in
Deck Thickness	10-gauge
Cutting Height	1.5 - 4.5 inches
Warranty	3-year / 300-hour (residential), 1-year / no-hour limit (commercial)
