SECTION 10: INSTRUMENTATION
10.1 Electronic Hour Meter—Registers Hour increments up to 9,999.9 total hours. This meter
records the cumulative time the engine is running.
10.2 Oil Pressure Light—NOT ON ZT or MZ MODELS—This light comes on upon placing the
ignition switch in the RUN position and stays lit until the engine is running and a safe oil
pressure is built up. If the light comes on during operation, shut the engine off immediately
and locate the problem or contact authorized Bad Boy Mower dealer.
10.3 High Temperature Buzzer—NOT ON ZT or MZ MODELS—Liquid-Cooled models are
equipped with a buzzer that will sound in the event of high water temperature.
IF THIS HAPPENS SHUT ENGINE OFF IMMEDIATELY! Allow engine to cool. Check for obstructions in
or around radiator or contact your local Bad Boy Mower Authorized Dealer.
10.1
10.1
PAGE 13
