Step 4 - Install a AC cable protective end cap at the end of AC cable
Step 5 - Connect Microinverters to the PV Modules
NOTE: When the DC cables are plugging in, the microinverter LED should immediately
blink red once, followed by three short green blinks. This will happen as soon as the
cables are plugged in, indicating that the microinverter is functioning correctly. This
entire function will occur within 5 seconds of plugging in the unit, so pay careful
attention to the LED when connecting the DC cables.
WARNING: Double-check to make sure all of the AC and DC wiring has been correctly
installed. Ensure that none of the AC and/or DC wires are pinched or damaged. Make
sure that all of the junction boxes are properly closed.
