Parts List
Part Description Qty
1 Saddle Extension Pad 1
2 Saddle Extension 1
3 Extension Pin 1
4 Saddle Extension Base 1
5 Screw M12 2
6 Saddle Pad 1
7 Saddle Screw 1
8 Saddle 1
9 Saddle Base 1
10 Front Wheel Axle Cover 1
11 Left Side Plate 1
12 Screw M6x20 4
13 Front Wheel Axle 1
14 Wheel Washer 4
15 Nut M20x1.5 4
16 Wheel Bearing 6003-Z 8
17 Front Wheel 6″ 2
18 Washer 12 4
19 Lock Nut M16 4
20 Pivot Support Rod Axle 1
21 Retaining Ring 18 2
22 Screw M8x25 4
23 Lock Washer 6 2
24 Screw M6x25 2
25 Side Handle 2
26 Bottom Plate 1
27 Lock Washer 8 12
28 Screw M8x16 10
29 Rear Wheel 8″ 2
30 Screw M10x20 2
31 Lock Washer 10 4
32 Handle Kit 1
33 Saddle Extension Set Screw 1
34 Screw M12x25 8
35 Lock Washer 12 8
36 Washer 10 2
Part Description Qty
37 Screw M10x25 2
38 Nut M18 2
39 Handle Yoke Axle 2
40 Rear Wheel Axle 1
41 Rear Wheel Bushing 1
42 Spring 1
43 Socket Positioning Pin 1
44 Fixed Pin 3.5x17 1
45 Handle Lever 1
46 Handle Bumper 1
47 Lower Handle 1
48 Handle Lock 1
49 Upper Handle 1
50 Screw M8x25 2
51 Hex Wrench Fixed Spring Base 1
52 Hex Wrench Fixed Spring 1
53 Hex Wrench 10 1
54 Right Side Plate 1
55 Hex Wrench Fixed Pin 1
56 Tie Rod 1
57 U-Joint 1
58 Hydraulic Unit 1
59 Lift Arm Shaft Bushing 2
60 Lift Arm Shaft 1
61 Pivot Support Rod Screw 2
62 Lift Arm 1
63 Lift Arm Stop Rod 1
64 Pivot Support Rod 2
65 Handle Yoke 1
66 Fixed Ring 1
67 Steel Ring 1
68 Clasp 1
69 Screw M6x12 2
70 Lock Washer 6 2
71 Support Base 1
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only, and are not available
individually as replacement parts. Specify UPC 193175456199 when ordering parts.
