3 Technical Characteristics
3.1 Technical specifications
Diamond channel cutter type BDN 452 BDN 453 BDN 454 BDN 455
Manufacturer Maschinenfabrik OTTO BAIER GmbH
Operating voltage (V / Hz) ~230 / 50 / 60
Power consumption (watt) 1650 1800 1800 2150
Protection class
/ II / II / II / II
Speed (min
-1
) 7800 7800 4100 7200
Disc diameter (mm) 150 150 185 185
Max. disc thickness (mm) 3.5 3.5 3.5 3.5
Cutting width (mm) 7 – 27 7 – 35 9 – 43 9 – 43
Cutting depth (mm) 7 – 30 7 – 45 15 – 60 15 – 60
Weight (kg)
Machine
1)
5.3 5.6 6.6 5.8
Cutting disc 0.220 0.220 0.380 0.380
Speed electronics Yes Yes Yes Yes
Sound measurement
2)
K = 3 dB
L
pA
(sound pressure) dB (A) 95 95 99 95
L
WA
(sound power) dB (A) 106 106 110 106
Vibration measurement:
6)
K = 1.5 m/s
2
Front handle (11)
1
m/s
2
2.79 2.79 2.11 3.32
Rear handle (2)
1
m/s
2
3.73 3.73 3.24 4.47
Diamond channel cutter type BDN 463 / 4 BDN 464 / 4 BDN 466 / 6
Manufacturer Maschinenfabrik OTTO BAIER GmbH
Operating voltage (V / Hz) ~230 / 50 / 60
Power consumption (watt) 2150 2400 2400
Protection class
/ II / II / II
Speed (min
-1
) 8200 8200 8200
Disc diameter (mm) 150 185 150
Max. disc thickness (mm) 3.5 3.5 3.5
Cutting width (mm) 7 – 35
3)
9 – 43
4)
7 – 35
5)
Cutting depth (mm) 7 – 45 15 – 60 7 – 45
Weight (kg)
Machine
1)
5.6 6.4 6.2
Cutting disc 0.220 0.380 0.220
Speed electronics Yes Yes Yes
Sound measurement
2)
K = 3 dB
L
pA
(sound pressure) dB (A) 95 96 96
L
WA
(sound power) dB (A) 106 107 107
Vibration measurement:
6)
K = 1.5 m/s
2
Front handle (11)
1
m/s
2
3.32 3.45 2.6
Rear handle (2)
1
m/s
2
4.47 4.61 3.8
1)
Weight without insert tool and connection cable.
2)
Measured values for noise determined according to EN 60745. Wear hearing protection!
3)
With a cutting width of 7 – 18 mm, a clear channel is formed.
4)
With a cutting width of 9 – 18 mm, a clear channel is formed.
5)
With a cutting width of 26 mm, a clear channel is formed.
6)
Total vibration values (vector sum in three directions) determined according to EN 60745 (continued on
next page).
