SERVICE MANUAL
4
Weights and Dimension Data
Approach Autograph Weight Data Table
MODEL Autograph 540 Autograph 625 Autograph 740 Autograph 745 Autograph 730 Autograph 765
Engine 2.2 Hdi 2.2 Hdi 2.2 Hdi 2.2 Hdi 2.2 Hdi 2.2 Hdi
Vehicle Designation 335 335 335 335 335 335
MTPLM 3500 Kg 3500 Kg 3500 Kg 3500 Kg 3500 Kg 3850 Kg
Mass in Running Order (MRO) 2828 Kg 2995 Kg 3042 Kg 3129 Kg 3067 Kg 3217 Kg
User Payload 672 Kg 505 Kg 458 Kg 371 Kg 433 Kg 633 Kg
Conventional Load (75 Kg per
person)
225Kg 75 Kg 75 Kg 225 Kg 75 Kg 375 Kg
Designated Passenger Seats
(excluding driver)
3 1 1 3 3 5
Essential Habitation Equipment 129 Kg 129 Kg 129 Kg 129 Kg 129 Kg 129 Kg
Gross Train Weight 6000 Kg 6000 Kg 6000 Kg 6000 Kg 6000 Kg 6000 Kg
MBTM 2000 Kg 2000 Kg 2000 Kg 2000 Kg 2000 Kg 1650 Kg
Maximum Tow Ball Nose Weight 80 Kg 80 Kg 80 Kg 80 Kg 80 Kg 80 Kg
Axle Weights
Front Axle Weight, in running
order
1566 Kg 1624 Kg 1485 Kg 1511 Kg 1588 Kg 1700 Kg
Rear Axle Weight, in running
order
1262 Kg 1368 Kg 1554 Kg 1515 Kg 1480 Kg 1518 Kg
Front Axle Limit 1850 Kg 1850 Kg 1850 Kg 1850 Kg 1850 Kg 1850 kg
Rear Axle Limit 2000 Kg 2000 Kg 2000 Kg 2000 Kg 2000 Kg 2000 Kg
