Baja DB30 - Front Fender Installation; Mount Front Fender

5
Front Fender Assembly
1. Install front fender. Make sure large
portion of fender is over wheel. Install
with rubber grommet between frame
and fender. Tighten with 8mm Nuts and
8mm X 25mm bolts provided.
Torque bolts to 15 ft/lbs
8mm Lock nuts
Rubber Grommets
8mm X 25mm bolt
Fender Orientation.
Larger part toward
front over wheel.
