VK-P10 Specifications
Total Energy Storage: 200 joules
Gain at 1kHz: (The following user-selectable values are available)
Input Mode Switch Gain Switch Gain
Direct position: Low 44dB
High 54dB
With step-up: Low 64dB
High 74dB
Signal-to-Noise Ratio: (A-weighted, referenced to 1mV)
Low position 75dB
High Position 78dB
With Step-Up 86dB
Absolute Polarity: Selectable through front panel
switch
Cartridge Loading:
Resistance: Selectable from 100Ω to 47kΩ
Capacitance: Selectable from 100pF to 1000pF
Inputs: Two sets (one RCA and one XLR)
Outputs: XLR Balanced
(XLR-to-RCA adapters available)
Tube Complement: 8 6922 and 2 6SN7
Power Consumption: 150 VA Max
Dimensions: 19” (W) x 5.5” (H) x 14” (D)
Weight: 35 lb. unpacked
