Indicator lamp
Indicates the settings that have been
selected for:
– Temperature: Ž
- 90°C.
– Spin speed: $ - 1400 rpm.
– Options/signal.
Display panel
Shows the settings that have been selected (e.g. spin speed,
drying time), the progress of the current programme and the
programme status.
Programme progress
4 N ' B ‘
Pre-wash, Main wash, Rinse,
Final spin, Drying.
Drying options
0 P e ‘ +
Time-controlled drying, Iron-damp,
Cupboard-dry, Extra-dry.
Auxiliary displays
2 ! @
? kg
Finished in time, Programme start, Childproof
lock, Fluff-removal cycle, recommended
load.
Indicator lamp Display panel
Washing and drying options –> page13
– temp °C (Temperature): individual adjustment of the
washing temperature.
– B centrifug. (Spin speed): individual adjustment of the
spin speed.
– Tecla opc. (Options): sets washing options.
– selec.: activation/deactivation of the selected
washing options.
– 0 pr. diferida (Finished in time): delays the
Programme start.
– secar
9 (Drying): sets the drying options
inicio/pausa (Start/Pause ):
starts and stops the washing programme –> page14.
Buttons
Programme selector –> page11
For switching the washer-dryer on and
off and for selecting the programme, can
be turned in both directions. Do not
adjust the programme selector while
washing/drying is in progress.
Programme selector
