7
Input connections: 59019 – bba™ - Balboa Bluetooth Audio Amp
Integrated
or
Integrated operation with control via panel.
NOTE:
Power must be supplied to the bba™ at
time of spa power up, so that the bba is
recognized by the BP spa control which
enables the integrated menu.
KEYPAD
CONTROL
Line input
White = Left
Red = Right
BASS GAIN TRIM
PWR/ ON/OFF
Optional Line Input
TV, MP3, Sat Radio or
other audio sources
or
Adaptor cable
BP Series Control
spaTouch™
TP800 panel
TP900 panel
25717 (Adapter Cable)
Optional extension cables
for flexibility in bba
placement:
CABLE EXTENSION TP
PANELS – 100 FT 25662-3
CABLE EXTENSION TP
PANELS – 25 FT 25662-1
CABLE EXTENSION TP
PANELS – 50 FT 25662-2
CABLE EXTENSION TP
PANELS – 7 FT 25662
