- 4 -
Issue 2
Mitre Integrated Technical Specification
MIXER
60 120 300
Rated output power
100V line 230V AC supply N/A 60W 166 Ohms 120W 83 Ohms 300W 33 Ohms
THD 1 kHz rated output
Aux input 230V AC supply Less than 0.5% typically 0.2%
Typical output power 1% THD
Aux input 230V AC supply N/A 80W 125 Ohms 150W 66 Ohms 340W 29 Ohms
Output regulation
(1 kHz 100V line) N/A Better than 1dB
Output voltages obtainable
(Pin selection) N/A 50 & 100V
Supply voltage AC 230V 50-60 Hz
Power consumption @ 230V
Quiescent (no external DC load)
Rated output power @ 1 kHz
20VA
N/A
12VA
150VA
18VA
300VA
26VA
700VA
Fuse protection
1 x AC supply 20 x 5 mm
2 x DC (amplifier) auto blade type
630mA(T)
1x1A(F)
1x5A(F)
2A(T)
5A(F)
3.15A(T)
10A(F)
6.3A(T)
20A(F)
1 x DC Aux output Self Resettable Fuse
Aux input phono stereo summed mono
Sensitivity
Frequency response -3 dB @
Signal to noise ratio
100mV @ 20k Ohms
40 Hz - 20 kHz
Better than 80 dB
Tone controls
Bass
Treble
± 12 dB @ 100 Hz
± 12 dB @ 12 kHz
Universal input (line)
Sensitivity
Frequency response -3 dB @
Signal to noise ratio
80mV @ 12K balanced
40 Hz - 18 kHz
Better than 70 dB
Universal input (Mic)
Sensitivity 600 µV balanced
Input impedance
Without phantom power
With phantom power 15V
12k Ohms
660 Ohms
Frequency response -3dB @ 40 Hz - 18 kHz
Common mode rejection ratio
50 Hz - 30 kHz Better than 60 dB
Signal to noise ratio terminated 200 Ohms Better than 60 dB
System busy output Open collector 0.5A @ 40V total max.
Aux line output level
Source impedance
0 dBm transformer isolated
100 Ohms
Power amplifier input
Sensitivity
Impedance
800mV
15K Ohms
Busy/restoration relay output 2 pole change-over 5A @ 100V max.
DC Aux output 30V @ 1.5A max.
4-zone relay output N/A N/A N/A 5A @100V max.
LED indicators x 5 1 per universal input (indicates busy state) 1 indicates presence of 24V Aux
supply
Terminations
AC supply input
Power amp input
Aux signal input
Universal input
Alarm trigger & 0dB line output
Busy/restoration relay output
Loudspeaker line output
3-pin, DIN IEC 6A
1 x phono
2 x phono, Stereo summed mono
6-pin, Screw terminated connector + 3-pin XLR
6-pin, Screw terminated connector
8-pin, Screw terminated connector
3-pin, Screw terminated connector
Dimensions (cm) (D x W x H) 340 x 430 x 90 340 x 430 x 132
Weight 7.1 Kg 11.2 Kg 12 Kg 18 Kg
