- 5 -
Issue 2
Mitre Tuner Specification
FM tuning range 87-108 MHz
Sensitivity for 40 dB signal to noise ratio
(ref. to ±22.5 kHz) 20 dBµ typical
IF frequency 10.7 MHz
IF rejection @ 98 MHz 70 dB typical
Image rejection @ 98 MHz 80 dB typical
AM rejection @ 98 MHz 70 dB typical
Antenna input impedance 75 Ohms unbalanced
AM tuning range 525-1605 kHz
Sensitivity for 30 dB signal to noise ratio
(ref. to 30% modulation) 40 dBµ typical
IF frequency 450 kHz
IF rejection @ 1050 kHz 55 dB typical
Image rejection @ 1050 kHz 36 dB typical
AGC @ 1050 kHz 60 dB typical
Antenna input impedance To suit loop antenna
Pre-set channel selection 7 FM 7 AM 1 Aux
Tuned frequency indicator 4 7 segment LED displays
Channel indicator 1 7 segment LED displays
Memory battery back-up 90 days
