REGULATOR CONFIGURATION PARAMETERS
TEMPERATURE PROBE PRESSURE PROBE
MEASUREMENT
RANGE
SENSOR MODEL
MEASUREMENT
RANGE
SIGNAL MODEL
A
RWF 40 C111
9XXX 0...130 °C Ni 1000 QAE2120 - - -
5XXX 0...500 °C Pt 1000 ZTR365 - - -
LC3 SENS PT10
0...130 °C
Pt 1000
JUMO-902524/25 - - -
0...500 °C JUMO-902020/10 - - -
B
RWF 40 C111 AXXX
0...1100 °C type K ZTC22D1NC
- - -
LC3 SENS CrAl - - -
C
RWF 40 C111 FXXX - - -
0..0.40 bar 4...20 mA C07 .
LC3 SENS 4.20 - - -
D
RWF 40 C111 GXXX - - -
0..0.40 bar 0...10 VAC QBE2002...
LC3 SENS 0.10 - - -
LEGEND
L1, 14, 1 POWER TENSION
2 NEUTRAL
43, 80, 81 CONTROL SIGNAL
X1 BURNER TERMINAL BOARD
X2S SECOND STAGE CONNECTOR
X16 POWER SUPPLY CONNECTOR N1
A1 EQUIPMENT
N1 ELECTRONIC REGULATOR
BT TEMPERATURE PROBE
TER THERMALCOUPLE
BP PRESSURE PROBE
