baltur TBL 85P - Technical Data; Operation; Standard Accessories

30 / 96
0006081053_200801
E
N
G
L
I
S
H
TBL TBL TBL TBL TBL
85P/ P DACA 105P/ P DACA 130P/ P DACA 160P/ P DACA 210P
BURNER FIXING FLANGE 2 2 2 2 2
ISOLATING GASKET 1 1 1 1 1
STUD BOLTS N° 4 N° 4 N° 4 N° 4 N° 4
M 12 M 12 M 12 M 12 M 12
EXAGONAL NUTS N° 4 N°4 N° 4 N° 4 N° 4
M 12 M 12 M 12 M 12 M 12
FLAT WASHERS N° 4 N° 4 N° 4 N° 4 N° 4
Ø 12 Ø 12 Ø 12 Ø 12 Ø 12
TECHNICAL DATA
TBL 85P
TBL 85P
DACA
TBL 105P
TBL 105P
DACA
TBL 130P
TBL 130P
DACA
TBL 160P
TBL 160P
DACA
TBL 210P
THERMIC CAPACITY MAX kW 850 1050 1300 1600 2100
MIN kW 200 320 400 500 800
OPERATION Two-stage
NOx EMMISION mg/kWh < 185 (Classe II EN 267)
MOTORE kW 1,1 1,5 2,2 2,2 3
r.p.m.
2800 2800 2800 2800
2800
ABSORBED ELECTRICAL POWER* kW 1,50 1,90 2,60 2,60 3,40
line fuse A
400 V
6 6 10 10 16
IGNITION TRANSFORMER
2 x 5 kV - 30 mA - 230 V/ 50 Hz
VOLTAGE
3N ~ 400 V ±10%- 50Hz
PROTECTION RATING
IP 40
FLAME DETECTOR
PHOTORESISTANCE
/NOISE** dBA 73 75,5 79 79 87
WEIGHT kg 82 88 92 92 95
Fuel max. viscosity (light-oil)
5,5 cst/20°C - 1,5° E / 20°C
FLOW RATE MAX kg/h 71,6 88,5 109,6 134,9 177
MIN kg/h 16,9 27 33,7 42,2 67,4
TECHNICAL DATA
*) Total absorption at start with ignition transformer on.
**) Noise levels measured by the manufacturer in the laboratory with burner running on test boiler, at maximum nominal thermal output (DACA verion burner).
STANDARD ACCESSORIES
