Bambi VT - Page 24

VTS250
Ref No. Description Part no.
1 Top panel BPB0354
2 3/8 x 10mm Tube elbow BPB0593
3 3/8 Bulkhead connector BPB0749
4 Safety valve BPB1084
5 1/4 x 6mm Tube elbow BPB0042
6 1/4 x 6mm Tube elbow BPB0758
7 1/4 x 63mm 0-160 Gauge BPB0748
8 Pressure switch BPB0550
9 Cabinet: RH panel BPB0352
10 1/4 x10mm Tube elbow BPB0276
11 Regulator BPB0510
12 Cabinet centre panel BPB0353
13 Cabinet back panel BPB0350
14 Cooling fan BPB0727
15 Fan guard BPB0355
16 2.0HP Motor mounting bracket BPB0516
17 1/8 x 6mm Push fitting BPB0154
18 On/Off valve BPB1079
19 M8 Hex full nut BPB0161
20 2.0HP Crankcase mounting brkt. BPB0517
21 20mm Rubber mount BPB0273
22 M8 Flanged nut BPB0130
23 40mm Rubber mount BPB0272
24 Cabinet LH panel BPB0351
25 1/8 x 6mm Elbow BPB0278
26 Delivery pipe BPB0508
27 3/8 x 10mm Tube elbow BPB0277
28 3/8 Elbow BPB0282
29 Non-return valve BPB0656
30 Solenoid valve / cable assembly BPB0545
31 After-cooler mounting bracket BPB0336
32 Cooling fan / housing: Large BPB0767
33 Cutout / Reset switch BPB0722
34 On/Off switch APT626
35 Drain valve BPB0895
36 Silencer BPB0588
37 Cabinet base BPB0348
38 Retaining washer BPB0559
39 Spacer BPB0082
40 M6 x 35mm caphead screw BPB0131
41 Swivel castor BPB0973
42 Motor mounting plate BPB0343
43 Swivel castor c/w brake BPB0974
44 59ltr vessel BPB0230
45 Inspection plug seal BPB0502
46 Inspection plug BPB0243
47 Cabinet front panel BPB0349
48 Thermal switch BPB0732
