Bambi VT - Wiring Diagrams - Single Phase

VT[H]75 / VT[H]150 / VT[H]200 /
VT250
VT[H]75D / VT[H]150D / VT[H] 200D /
VT250D
VT300/400
VT300D/400D
DO NOT ALTER!!
Wiring Diagrams - SINGLE PHASE
K
- Live
- Neutral
- Earth
KKEY:
31
A1 15
18 A2
DO NOT ALTER!!
VT300/400/300D/400D
[Electrics enclosure]
Motor 1
Fan 1 Solenoid 1 Fan 2 Solenoid 2
Motor 2
Supply
1
5
To electrics
enclosure
1 - Supply
2 - Solenoid
3 - Earth
4 - Motor
5 - Pressure Switch
6 - Cooling fan
7 - Timer box [VT250D only]
