Bambi VT - Page 26

24
VTS250D
Ref No. Description Part no.
1 Top panel BPB0354
2 Cooling fan BPB0727
3 Back panel BPB0350
4 Cabinet RH panel BPB0352
5 Cabinet centre panel BPB0353
6 1/4 x 6mm Tube elbow BPB0758
7 1/4 x 63mm 0-160 gauge BPB0748
8 1/4 x 10mm Tube elbow BPB0276
9 Regulator BPB0510
10 1/4 x10mm Elbow BPB0820
11 On/Off valve BPB1079
12 Drain valve BPB0895
13 On/Off switch APT626
14 Cutout/Reset switch BPB0722
15 Water bottle c/w cap and cage BPB0088
16 Safety valve BPB1084
17 3/8 Bulkhead connector BPB0749
18 3/8 x 10mm Tube elbow BPB0593
19 Pressure switch BPB0550
20 Aftercooler c/w fittings / guard BPB0869
21 3/8 x Plated elbow BPB0282
22 Delivery pipe BPB0728
23 Delivery pipe BPB0798
24 1/8 x 6mm Elbow BPB0044
25 Solenoid valve / cable assembly BPB0545
26 Air filter - Centrifugal - Coalescing BPB1359
26a 1/4bsp x 1/8bsp Reducing Bush BPB0041
27 Element for BPB1359 BPB1367
28 Delivery pipe BPB0508
29 3/8 Bulkhead connector BPB0749
30 3/8 Elbow BPB0629
31 Twin tower dryer BPB0836
32 Relief valve: 10bar BPB1084
33 Extension piece BPB0150
34 59ltr vessel BPB0230
35 1/4 x 6mm Tube elbow BPB0042
36 Inspection plug seal BPB0502
37 Flanged inspection plug BPB0243
38 Non-return valve BPB0656
39 3/8 x 10mm Tube elbow BPB0593
40 Motor mounting plate BPB0343
41 Cabinet LH panel BPB0351
42 Swivel castor BPB0973
43 Swivel castor c/w brake BPB0974
44 M6 x 35mm cap head bolt BPB0131
45 Spacer BPB0082
46 Retaining washer BPB0559
47 Cabinet base BPB0348
48 M8 Hex nut BPB0161
49 Cabinet front panel BPB0349
50 After-cooler mounting bracket BPB0336
51 M8 Flanged nut BPB0130
52 20mm Rubber mount BPB0273
53 2.0HP Crankcase mounting bracket BPB0517
54 40mm Rubber mount BPB0272
55 2.0HP motor mounting bracket BPB0516
56 Fan guard BPB0355
57 Thermal switch BPB0732
