1TT!–TIMER!+!TERMOREG OLATO RE!-!Reference!Manual!!-!Pag.!5!di!7!
parameters!
!
Description!
!
!!!!!!!!!!!!!!!!!!!!!!Values!
!
Default!
!
Note!
SP!
(*)
!
Setpoint!!
-!99!::![!Maximum!Setpoint]!!!!!!!
20°C!
!
!!!!!!!!!!!!!!!!!!!!!!!!!!!Disposable!!Parameters!with!the!“123”!password!only!
AL!
Alarm!
[min]!::![max]!
100°C!
!
Int!
!!!!!!!!!!!!!!Kind!of!probe!
tcJ!
Termocouple!J!
tcH!
Termocouple!K!
tcb!
Termocouple!B!
tce!
Termocouple!E!
tcn!
Termocouple!N!
tcr!
Termocouple!R!
tcs!
Termocouple!S!
tct!
Termocouple!T!
pt1!
Pt100!
p10!
Pt1000!
!
TC!J!
!
Act!
Working!method!
Hot!
Heating!
Col!
Raffreddamento!
Hot!
Setting!COL!the!
controller!!will!work!by!
ON/OFF!method!w.algor.!
Eco!
!ECO!mod!
0!(off)!::!999!
0°C!
!
BSC!
Gradient!of!ramp!
0!::!1!
1!
The!setpoint!can!
automatically!change!
nSP!
Min.!setpoint!
-!99!::!999!
-!30!°C!
!
mSP!
Max.!setopoint!
-!99!::!999!!
400°C!
!
Tc!
Time!of!Cycle!
0,1!::!999 !
15!s!
!
PB!
Proportional!Band!
0!(regolazione!ON-OFF)!:!100!
2!%!
Percentage!of!the!range!
Ti!
Integral!Time!
0!::!999!
120!s!
Integral!Time!
td!
!!!!!!!!!!!!Derivative!Time!
-!1!::!999!
30!s!
Select!-1!to!work!
automatically!in!!Ti/4!
OFS!
!!!!!!!!!!!TemperatureOffset!
-!100!::!+100!
0!°C!
!
HSO!
Positive!differential!off!SET!
0!::!999!
0!°C!
Used!in!case!of!!ON-OFF!
reg.!
HSU!
Negative!differential!off!SET!
0!::!999!
1!°C!
Used!in!case!of!ON-OFF!
!
ALM!
!
Relay!Alarm!Mode!
!
Absolute!Band!Alarm!!!!!!!Relay!-!(!1!off!/!2!on!)!
Finestra!o!deviazione!!!!!!!Relay!-!(!4!off!/!3!on!)!
!
!
1!
!
ALS!
!!!!!!!!!!!!Setpoint!Alarm!
0!::!1!
0!
Solo!per!allarme!!relè!
finestra!o!deviazio ne !
ALH!
Absolute!High!Alarm!.!!
!0!::!999!
600!°C!
!
