B&K ST2140 - Level Controls

Page 4
12998 rev 0004
Rear Panel View
1. AC fuse holder 5. RCA inputs (unbalanced)
2. AC Input receptacle 6. Level controls **
3. Speaker outputs 7. Amplifier control muting input/output
4. Balanced inputs
** OPTIONS AVAILABLE FOR THE ST2140 AMPLIFIER
NOTE: THE CENTER CHANNEL IS NOT AVAILABLE ON THE ST2140 AMPLIFIER
Rear panel description
1. AC fuse holder
- Holds the AC Line fuse. This fuse is an 8 Amp / 250 Volt
Slow Blow fuse. Replace with same type and value fuse
only.
2. AC Input receptacle
- For attaching the supplied AC power cord to the
amplifier.
3. Speaker outputs
- For connecting the speakers to the amplifier. Explained
further on page 7.
