Banshee Darkside - Torque Specifications; Maintenance Schedule

!
!
Torque specs!
!
Torque (Nm)!
Lower Link Pivots!
8!
Top Link Pivots!
8!
Rear Thru Axle!
8!
Rear Thru Axle Lock Nut !
3!
Shock Bolt - Frame side (front) !
10!
Shock Bolt - Swing Arm (rear)!
12!
Derailleur Hanger Bolt!
5!
!
Maintenance schedule!
We recommend following this maintenance schedule to ensure optimal performance. !
Check bolts are tight!
Before every ride!
Clean and re-grease pivot assemblies!
Every 50 hours of riding!
Bearing replacement!
Every 250 hours of riding!
!
If riding in wet or very dusty conditions you should carry out maintenance more regularly
as you see fit. !
!
