Getting to Know the Radio
Radio Overview
1. Antenna
2. Flashlight
3. Volume Knob (On/Off Switch)
4. LCD Display
5. CALL Button
6. MONI Button
7. PTT Button
8. VFO / MR Button
(Frequency Mode/ Channel Mode)
9. LED Indicator
10. Strap Buckle
11. Accessory Jack
12. A / B Button
(Frequency Display Switch)
13. Band Button (Not Present on Recent Models)
14. Numeric Keypad
15. Speaker & Microphone
16. Battery Pack
17. Battery Contacts
18. Battery Remove Button
