Barco Encore - Page 7

PCs (DVI)
Dual Head Graphics Cards
Destination 3
Destination 2Destination 1
OutOut
ScreenPRO-II
VGA Monitor VGA Monitor
PCs (DVI)
DVR
In
Out
Destination 5: PresentationPRO-II Aux
Destination 4: ImagePRO Aux
16 x 16 MatrixPRO RGBHV Router
16 x 16 MatrixPRO SDI Router
Controller SC or LC
Encore Video Processor, 3 M/E
Destination 1
Sample System — Single Screen Configuration Sample System — Multi Screen Configuration
PG 2
PVW
PG 1
• Non-stack system, up to 6 layers
• 1 x 3 M/E Video Processor
• 1 x SDI Router
• 1 x RGBHV Router
• 5 destinations:
1) Projector
2, 3) Aux Monitors
4) ImagePRO Aux
5) PresentationPRO-II Aux
Program Preview
6 x RGBHV
1 x Bgnd
1-6
6 x SDI
1-6
1 x DSK
7
8
7
8
LCD
Destination 2 Destination 3
9
10
In
Out
16 x 16 MatrixPRO RGBHV Router
16 x 16 MatrixPRO SDI Router
Controller SC or LC
Encore Video Processor #1, 3 M/E
PG 2
PVW
PG 1
• Non-stack system, up to 6 layers
• 2 x 3 M/E Video Processors
• 1 x SDI Router
• 1 x RGBHV Router
• 5 destinations:
1, 2) Projectors
3) ScreenPRO-II
4, 5) Aux Monitors
Program 1 Program 2
6 x RGBHV
1 x Bgnd
1-6
6 x SDI
1-6
1 x DSK
7-12
13
7-12
13
14
15
Preview 1 Preview 2
Encore Video Processor #2, 3 M/E
PG 2
PVW
PG 1
14
6 x RGBHV
1 x Bgnd
6 x SDI
1 x DSK
VGA Monitor VGA Monitor
Destination 4 Destination 5
16
Program Preview
PG 2
PVW
PG 1
Up to 16 SDI Inputs
Up to 16 Analog Inputs
Up to 16 SDI Inputs
Up to 16 Analog Inputs
Background DSK
Ethernet Switch
(Local Network Only)
Ethernet Switch
(Local Network Only)
Background
DSK
