Bard W17A1 - Page 4

Form No. S3397-1112
Supersedes S3397-712
Page 4 of 12
W30A & W36A HIGH SPEED TOTAL AND VENTILATION AIRFLOW
0
100 200 300 400 500 600 700 800 900
1000 1100 1200
ABCDEF
Vent Position
Airflow (cfm)
Total Air 0 ESP Total Air .15 ESP Total Air .3 ESP Vent Air 0 ESP Vent Air .15 ESP Vent Air .3 ESP
W30A & W36A LOW SPEED TOTAL AND VENTILATION AIRFLOW
0
100 200 300 400 500 600 700 800 900
1000
ABCDEF
Vent Position
Airflow (cfm)
Total Air 0 ESP Total Air .15 ESP Total Air .3 ESP Vent Air 0 ESP Vent Air .15 ESP Vent Air .3 ESP
0
100 200 300 400 500 600 700 800 900
1000 1100
ABCDEF
Vent Position
Airflow (cfm)
Total Air 0 ESP Total Air .15 ESP Total Air .3 ESP Vent Air 0 ESP Vent Air .15 ESP Vent Air .3 ESP
W17A/W18A & W24A TOTAL AND VENTILATION AIRFLOW
Commercial Room Ventilator Performance Data - CRV-2
Commercial Room Ventilator Performance Data - CRVS-3 and CRVP-3
