Bareknuckle Welterweight - Airless Paint Sprayer OPERATING INSTRUCTIONS & SAFETY MANUAL Bareknuckle Welterweight - Airless Paint Sprayer OPERATING INSTRUCTIONS & SAFETY MANUAL | 12 | 13
Clean Sprayer immediately to prevent permanent damage. Clean Sprayer immediately to prevent permanent damage.
13
13
13
13
13
PAINTING CLEARING SPRAY TIPPAINTING TECHNIQUES
Before painting, ensure the Sprayer has been primed (see Priming
and Startup steps) and verify that Nozzle Tip is aligned properly.
Note: Remove or cover objects that you want to protect
from overspray and paint mist.
Occasionally, the Spray Gun Tip will become clogged with paint.
Follow these instructions to clear Spray Gun Tip.
Before painting, ensure the Sprayer has been primed (see Priming
and Startup steps) and verify that Nozzle Tip is aligned properly.
Keep the gun approximately 30cm from the surface.
1. Once primed, adjust nozzle to
Spray setting.
1. Switch power off and set Trigger Lock.1. Keep gun straight and move
arm across at a steady rate
while staying 30cm from the
surface .
2. Do not fan the gun or paint will
be uneven.
3. Overlap strokes by half, always
aim stroke at bottom edge of
last stroke.
Overlap
Strokes
2. Start spraying at the lowest
setting on the Pressure Control
Knob and increase pressure as
needed by turning clockwise to
create a good spray pattern.
14
14
2. Adjust nozzle to clean setting.
14
5. Unlock Trigger.
14
6. Spray into waste bucket until
clog clears.
14
7. Release Trigger and engage
Trigger Lock.
14
8. Adjust nozzle to Spray mode.
14
3. Turn Spray/Prime Switch to Spray mode.
14
4. Turn power on.
14
Returns not accepted & warranty void if sprayer is
not properly cleaned immediately after every use.
Returns not accepted & warranty void if sprayer is
not properly cleaned immediately after every use.
