Barnstead E-pure - Figure C Exploded View (Pump)

17 Barnstead |Thermolyne • 800-553-0039
Key
Number
Description Part Number
1. Check valve 02214
2. Adapter 03039
3. Plug FS550X1
4. Nipple PM550X2
5. Pump 100 VAC &
120 VAC
PU582X1A
240 VAC PU582X2A
6. Fuse 100 VAC &
120 VAC
FZX15
2 Required
Fuse 240 VAC 04420
2 Required
7. Fuse holder FZX26
8. Switch ON/OFF SWX84
9. Pump interlock 04247
10. Elbow 05766
11. Pressure regulator 02280
Figure C: Exploded View (Pump)
