15
SINGLE SETPOINT CONTROLLER
Note
Tune has completed when “tunE”
stops flashing on display.
3. Press the SCROLL button. Display
will read, “tunE.”
4. Press the UP or DOWN button to
select, “on.”
5. Simultaneously press the PAGE and
SCROLL buttons to return to the
HOME DISPLAY. The display will
alternately flash between “tunE” and
the HOME DISPLAY while tuning is in
progress.
6. The controller will then turn the heat-
ing on and off to induce an oscillation.
When the measured value reaches
the required setpoint the first cycle will
end.
7. Tuning will be complete after two
oscillation cycles and then the tuner
will turn itself off.
8. Normal control function will resume
after the controller calculates tuning
parameters.
