Barracuda CloudGen Firewall
F80 Revision A 3 / 6
Certifications & Compliance
CE emissions Yes
CE electrical safety Yes
FCC emissions Yes
ROHS compliant Yes
Power & Efficiency
Power supply type External
Power type [AC/DC] AC
Input rating [Volts] 100-240
Input frequency [Hz] 50-60
Auto sense Yes
Wattage / max. power draw [W] 45
Max. power draw (@ 230V) [A] 0,2
Max. heat dissipation [W] 19
Max. heat dissipation [BTU] 65
Energy efficiency [average] > 85%
The hardware specifications list was valid at the time this manual was published. The listed
components are subject to change at any time, as Barracuda Networks may change hardware
components due to technological advancements. Therefore, the list may not reflect the current
hardware configuration of the Barracuda appliance it was delivered with.
Wall Mount Kit
This appliances is shipped with a wall mount kit. Print the Barracuda CloudGen Firewall Wall Mount Jig
to use as a template when drilling the required holes. Do not scale the PDF when printing.
LEDs and Acoustic Signals
Your appliance is equipped with a variety of LEDs and acoustic signals. The front panel of
the Barracuda CloudGen Firewall F80 A contains one power LED (blue), one disc LED (green), one
status LED (red), and 4 port LEDs. On the back panel, you can see one power button LED and various
port LEDs. Two acoustic signals indicate the status of installation. The tables below show the different
meanings of the different glowing states and acoustic signals:
