Status LED
Your appliance is equipped with a variety of LEDs. One of them is the Status LED. It is labeled either
with a heart symbol or the term Status. It indicates the appliance’s operational state by changing
colors between green, orange, and red and by changing between blinking and steady glowing. The
table below shows the different meanings of the different glowing states.
Your appliance is equipped with a variety of LEDs and acoustic signals. The front panel of
the Barracuda NG Firewall F80 contains one power LED (blue), one disc LED (green), one status LED
(red), and 4 port LEDs. On the back panel, you can see one power button LED and various port LEDs.
Two acoustic signals indicate status of installation.
LED Color Glowing State Meaning
All LED Off Off
Appliance is powered off or installation has not initialized far
enough for LED control when installation is started.
Power LED -
BLUE
steady Appliance is plugged in and is on.
Status LED - RED Off
Power LED on and Status LED off: Box is running normally, or
installation has finished successfully.
Steady
Appliance is halted and may be disconnected, or an error
occurred preventing the Barracuda NG Firewall from entering the
up state.
Blinking slowly
(1/s interval)
Normal installation, or appliance is either booting, shutting down,
or performing a system update.
Blinking fast
(4/s interval)
Error during installation, or appliance is in ART mode.
Disc LED -
GREEN
Blinking Appliance is accessing the internal storage.
Port LEDs (front)
- GREEN
Blinking Port in use (Data transfer).
Port LEDs (back)
- GREEN
Left blinking Port in use (Data transfer) – Yellow (10/100 Mbps).
Right steady Port is on.
Acoustic Signal Frequency Meaning
Beep
1 time
(.)
Appliance is booting.
Beep
3 times
(...)
Installation was completed successfully; appliance is halted for
reboot. After reboot, one beep will again indicate booting.
Beep
3 times long
(_ _ _)
Error during installation.
