Installation and operation
104304 13 / 30
– sufficiently large, and thus enabling usage of the appliance with no
problems;
– easily accessible;
– well ventilated.
• The appliance may be loaded and unloaded with a forklift truck or a pallet truck,
with the length of over half of the length of the appliance.
• The lifting equipment must be selected according to dimensions of the packed
appliance/components and the weight of the appliance.
• During operation follow all the necessary precautions in order not to damage the
appliance.
• Remove cardboard packaging from the wooden base, on which the appliance is
standing.
• Then lift the appliance with a suitable lifting equipment (lift truck or the like) and
remove he wooden base.
• Place the appliance in a suitable location.
Requirements for Place of Installation
When selecting the place of installation, provide for the following conditions:
– ambient temperature may not drop below 10°C (50°F) and rise above
43°C (110°F);
– water temperature may not be below 10°C (50°F) nor above 32°C (90°F)
(Fig. 4 at the beginning of the operating instructions);
– water supply pressure may not be below 0.1 MPa (1 bar) nor above
0.5 MPa (5 bar). If the pressure exceeds 0.5 MPa, install a pressure
reducer between water supply and the appliance (Fig. 5);
– there may be no heat sources in the vicinity,
– the appliance may not be subject to direct sunlight (Fig. 6);
– the location must be free of dust, as the condenser of the cooling unit
may clog rapidly (Fig. 8);
– the fan of the cooling unit may not be covered (Fig. 8),
– the appliance may not be installed in plunged areas, as in the case of
possible leakages, the coolant will be sinking down (Fig. 15),
– there may be no fuels, flammable nor explosive materials within the
radius of 3 m, and there must be sufficient air circulation provided for
(Fig. 19).
• Maintain minimum clearance from walls and other objects: 150 mm at the rear,
and 50 mm at both sides (Fig. 3).
