Put all connected to the panel
wires on the bottom of the flush
mount bracket.
All the protruding from the wall
and connected to the panel wires
must be carefully bent in
a semicircle in so that the upper
part of the wiring bundle is higher
than the hole for inserting cables
from the wall into the inside
of the bracket.
18
14
Apply a 3-4 mm layer of silicone
sealant around all wires coming
out of the slots in the insulating
rectangle.
The sealant must be applied
to the top of the joint between
the wire and the insulating
rectangle.
17
Silicon
sealant
