Apply a thin layer of silicone
sealant along the perimeter
of the niche with the connectors
оn the panel rear side and place
the protective rectangle in a niche
(where all connectors are)
on the panel rear side.
15
Silicon
sealant
Apply a 3-4 mm layer of silicone
sealant around the niche with
the placed insulating rectangle,
so that the sealant falls precisely
on the joint of the rectangle
and the back plastic cover
of the panel.
16
Silicon
sealant
Switch and connect the
protruding from the wall
and passing through the
insulating rectangle wires to the
necessary connection cords from
the panel kit.
13
Join all the resulting connectors
at the ends of the wires to their
corresponding response parts
on the panel rear side.
14
Tape
