Base Products Corporation www.basepump.com 800 554 1426 page
Models: RB750, HB1000, CB1500 Copyright by Base Products Corporation 2015 Rev. May/2015
Suction/Discharge Options
Basic Outdoor Installation
Standard Outdoor Discharge
Basepump mounted on side of ceiling joist;
Discharge to exterior.
Perpendicular Outdoor Discharge
Basepump perpendicular to exterior wall
with discharge turned at an angle.
Under Joist Outdoor Discharge
Basepump mounted under ceiling joist with
Discharge hose sloping upward and out.
Pump does not need to be directly above the sump in
case of an obstacle such as a heat duct, electrical
panel, window, stairway, etc.
Horizontal distance up to 10 Feet across.
Shared discharge with Primary Pump. You must have a fully
functional check valve below the tee and above the primary
sump pump or you will flood the basement.
