MATRIX 5000 / 6000 SERIES ELECTRICAL CABLING
Power Cord
Connector
HEAD END
CONTROL
BOX
FOOT END
Optional Battery
Cable Connector
Foot Actuator
Actuator Cable
Power Cord
Hand Control Pendant
Control Box
Actuator Cable
Actuator Cable
Actuator Cable
HI/LO Actuator
(Head End)
HI/LO Actuator
(Foot End)
Head Actuator
Control Cable
