Zenith aps seRies
BED OPERATIONS - TRENDELENBERG/REVERSE TRENDELENBERG
Basic American Medical Products, a division of GF Health Products, Inc. www.grahamfield.com 999-0831-190A Service Manual
18
1. Make sure the Hi/Lo function on the staff
control panel is not locked out (orange
lock icon). To unlock, press the Key icon #1
and Hi/LO Locked button #2 at the same
time.
2. To move the bed to the Trendelenberg
position (foot end up), press on button #3.
3. To move the APS bed into the Reverse
Trendelenberg position (head end up),
press on button #4.
1 2 3
4
NOTE: THE TRENDELENBERG AND REVERSE
TRENDELENBERG FEATURE CAN ONLY BE
ACCESSED USING THE STAFF CONTROL. IT
CANNOT
BE ACCESSED USING THE HAND
CONTROLLER/PENDANT.
