- 12 -
INSTALLATION GUIDE
*For assemblies including ange nuts (intergrated washer nuts), you will not have at washers in your kit.
16
SECURE THE INSTALLATION
Once the pole is inside, secure
the installation by installing the
removable front cover (E).
16.1 16.2
17
INSERT THE PRESSURE PLATE
Insert the pressure plate (F) behind
the pole.
17.1 17. 2
18
INSERT THE HANDLE BOLTS
Screw the 2 handle bolts (I) into
the 2 welded nuts on the back of
the main post holder (B).
Screw until the pressure plate (F) is
rmly squeezed against the pole.
PROBASE is now ready to use.
18.1 18.2
