AW00098506000 Specifications, Requirements, and Precautions
Basler ace Camera Link 4
Specification acA2040-180km acA2040-180kmNIR acA2040-180kc
Sensor Resolution
( H x V pixels)
2048 x 2048 2046 x 2046
Sensor Type CMOSIS CMV4000
Progressive scan
CMOS
Global shutter
CMOSIS CMV4000--2E12M
Progressive scan CMOS
Global shutter
CMOSIS CMV4000
Progressive scan
CMOS
Global shutter
Optical Size 1"
Effective Sensor Diagonal 15.93 mm
Pixel Size 5.5 µm x 5.5 µm
Max Frame Rate
(at full resolution and
10-bit sensor depth)
180 fps
Mono/Color Mono Mono (NIR) Color
Sensor Bit Depth 12 bits or 10 bits (selectable)
Data Output Type Camera Link base, medium, or full configuration
Camera Link Connectors Two 26-pin SDR connectors (also known as Mini Camera Link connectors)
One 4-pin M5 receptacle
Camera Link Clock Speed 32.5 MHz, 48 MHz, 65 MHz, 82 MHz (selectable)
Camera Link Tap Geometry 1X2-1Y, 1X3-1Y, 1X4-1Y, 1X6-1Y, 1X8-1Y, 1X10-1Y
Pixel Formats Mono 8
Mono10
Mono 12
Bayer GB 8
Bayer GB 10
Bayer GB 12
Synchronization Via hardware trigger, via software trigger, or free run
Exposure Time Control Trigger width or timed
Power Requirements PoCL (Power over Camera Link compliant)
+12 VDC (± 10 %), < 1 % ripple, supplied via the camera’s 4-pin connector
Power Consumption 3.0 W (typical) @ 12 VDC
I/O Lines 3 input lines (CC1 to CC3) and 1 output line (via Camera Link spare bit)
1 GPIO (can be set to operate as an input or an output)
Power supplies must meet the SELV and LPS requirements (see page 16).
Lens Adapter C-mount
Size
(L x W x H)
43.5 mm x 29.0 mm x 29.0 mm (without lens adapter or connectors)
58.9 mm x 29.0 mm x 29.0 mm (with lens adapter and connectors)
Weight < 100 g (typical)
Table 2: General Specifications (acA2040-180km, acA2040-180kmNIR, acA2040-180kc)
