V/OCT CALIBRATION MODE
+1 -1
SHAPE
−
+
CTRLSYNC EXTFM INDEX
−
+
INDEX
MOD
CTRL
A
B
SHAPE
E
F
PITCH
FM
INDEX
OCT
OSC
RATIO
OSC
PULSE MAIN OCT OSC
V/OCT
PIzza
SEMI
LONG
EXT
FINE
LONG:SET
LONG:ASSIGN
G/H
C/D
WAVE
RING
FOLD
+2
0
DETUNE
OCTAVE
TUNE
START
AUTOMATIC
CALIBRATION
EXTERNAL
CALIBRATION
VO CT
SOURCE
V & V
HOLD PITCH & SHAPE TO ENTER THE
V/OCT CALIBRATION MODE (ALL LIGHTS
COME ON) HOLD BOTH TO LEAVE
PRESS THE PITCH BUTTON TO START
AUTOMATIC CALIBRATION
 CONNECT ACABLE FROM OCT OSC
TO VO C T
 WAIT FOR ALL LIGHTS TO GO ON
AND THEN DISCONNECT THE CABLE
PRESS THE OCT OSC BUTTON TO START
EXTERNAL CALIBRATION
 PLUG ACABLE FROM YOUR VOCT
SOURCE TO THE VOCT INPUT OF
PIZZA.
  IS BLINKING  APPLY V C NOTE
IN LOWEST OCTAVE ON YOUR VOCT
SOURCE.
 PRESS THE OCT OSC BUTTON TO
LEARN WHAT V MEANS.
  STARTS BLINKING  APPLY V ON
YOUR VOCT SOURCE. PLAY ANOTE
THAT’STWO OCTAVES HIGHER V
 PRESS OCT OSC BUTTON TO LEARN
WHAT V MEANS AND PIZZA WILL
RETURN TO VOCT CALIBRATION
MODE.
14 – PULSE output (-5V to +5V)
PULSE outputs apulse version of the MAIN Oscillator. The VCA CTRL
destination does not apply to it. The width of the pulse is set by the FM
INDEX fader and its modulation.
15 – MAIN output (-5V to +5V)
The MAIN output outputs the MAIN oscillator after FM, FOLD, and RING.
This output is affected by the bipolar VCA CTRL destination.
