Batca Fusion 2 - Page 3

www.batcafitness.com 3 Fusion 2 Owner’s Manual
Frame Components
Accessories
Upholstery
ITEM NO. PART NO. DESCRIPTION QTY
156 BFC-10103 Strap Handle 4
ITEM NO. PART NO. DESCRIPTION QTY
31 BFU-10117 Large Bottom Pad 1
11 BFU-10119 Head Pad 1
32 BFU-10120 Back Pad With Lumbar 1
43 BFU-50187 Large Roller 1
28 BFU-50189 7" Roller 6
ITEM NO. PART NO. DESCRIPTION QTY
1 BFM-10593 Rear Base 1
2 BFM-10566 Right Vertical Support 1
3 BFM-10567 Left Vertical Support 1
4 BFM-10568 Middle Base 1
5 BFM-10569 Middle Pole Assembly 1
6 BFM-51044 Guide Rod Holder 1
7 BFM-51022 1 1/4" Spacer 6
9 BFM-50529 Rubber Donut 2
10 BFM-50256 Weight Plate 19
12 BFM-51051 Guide Rod 2
13 BFM-10570 Right Arm Assembly 1
14 BFM-10574 Left Arm Assembly 1
15 BFM-10573 Functional Arm Mount 1
16 BFM-10571 User Right Functional Arm 1
17 BFM-10572 User Left Functional Arm 1
18 BFL-50197 Middle Pole Connector Plate 2
19 BFL-50203 Pulley Holder Connector Plate 1
20 BFM-10577 8" Telespar 1
21 BFM-10578 Seat Frame Assembly 1
24 BFM-10579 10" Chrome Adjustment 1
25 BFM-10141 Knee Alignment Roller 1
30 BFM-10580 Back Chrome Adjustment 1
33 BFM-10581 Leg Extension/ Curl Frame 1
35 BFM-51080 .45” Spacer 1
36 BFM-10582 Functional Arm Swivel Pulley 2
37 BFM-10583 Top Swivel Pulley Holder 2
38 BFM-51082 Weight Stack Shroud 2
39 BFM-10584 Leg Extension Shaft 1
40 BFM-10585 Leg Extension Cam Assembly 1
41 BFM-51084 1 1/4" OD x .120 Wall x .225" Spacer 1
42 BFM-10586 Leg Extension Arm Assembly 1
44 BFL-50207 Hold Down Adjustment Plate 1
45 BFL-50211 Plate 1
46 BFM-10587 Knee Hold Down Assembly 1
47 BFM-51094 2” Axle 1
48 BFM-10588 Knee Hold Down Handle 1
50 BFL-50221 Pulley Plate 1
53 BFM-51143 8” Anti-Deflection Plate 1
54 BFM-51148 1" x 13 3/16" Arm Shaft 1
77 BFM-50505 3 1/2" Pulley Cover 11
79 BFM-10603 Left Arm Adjustment Handle 1
80 BFM-10602 Right Arm Adjustment Handle 1
87 BFM-51158 1" OD x 25/64" ID Spacer 1
91 BFM-10607 Press Arm 2
93 BFM-10609 Pulley Holder 2
94 BFM-10611 Criss-Cross Free Floater 1
96 BFM-10610 Lower Pulley Holder 2
105 BFM-10612 Cable Tie Out Plate 1
107 BFM-10299 Top Plate 1
108 BFM-50258 Selector Shaft 1
121 BFM-50222 2 9/16” Axle 1
122 BFM-50931 3” Axle 1
123 BFM-51173 Weight Stack Pull Pin 1
180 BFM-51130 Front Pivot 1
185 BFM-51158 Spacer 1
