Batca Fusion 2 - Page 4

Batca Fitness Systems 4 Fusion 2 Owner's Manual
Hardware
Cables
ITEM NO. PART NUMBER DESCRIPTION QTY
8 BFH-50173 3 1/2" Pulley 31
22 BFH-50103 1/2" Flanged Bushing 4
23 BFH-50102 5/8" Flanged Bushing 2
26 BFH-50222 Rubber Bumper 2
27 BFH-50221 3" Plastic Washer 4
29 BFH-50252 Plastic Collar 6
34 BFH-50101 1" Flanged Bushing 28
49 BFH-50280 1" Round Plastic Cap 5
51 BFH-10002 Threaded Bearing 2
55 BFH-50165 1" Snap Ring 9
56 BFH-50146 3/8" Flat Washer (Black) 113
57 BFH-50122 HCS 3/8"-16 X 2 1/4" P5 21
58 BFH-50157 3/8"-16 Nylock (Black) 69
59 BFH-50270 HCS 3/8"-16 X 5 1/4" P5 8
60 BFH-50147 3/8" Lock Washer (Black) 16
61 BFH-50119 HCS 3/8"-16 X 1 1/4" P5 4
62 BFH-50124 HCS 3/8"-16 X 2 3/4" P5 8
63 BFH-50125 HCS 3/8"-16 X 3" P5 5
64 BFH-50251 1/2" Flat Washer (Black) 4
65 BFH-50138 HCS 1/2”-13 X 3 1/2” P5 1
66 BFH-50139 HCS 1/2”-13 X 4 1/4” P5 1
67 BFH-50136 HCS 1/2”-13 X 3” P5 1
68 BFH-50155 1/2"-13 Nylock (Black) 3
70 BFH-50121 HCS 3/8"-16 X 2" P5 12
72 BFH-50274 HCS 3/8"-16 X 4 3/4" P5 6
73 BFH-50285 HCS 3/8"-16 1 3/4" P5 2
74 BFH-50132 HCS 3/8"-16 X 5 1/2" P5 2
75 BFH-50605 3/8" Pulley Spacer 2
76 BFH-50123 HCS 3/8"-16 X 2 1/2" P5 3
92 BFH-50256 1/2” Jam Nut 6
95 BFH-50174 4 1/2" Pulley 4
98 BFH-50253 Beveled Leveler 2
99 BFH-50149 3/8"-16 Jam Nut (Zinc) 6
110 BFH-51174 Large Logo/Chrome & Red 2
111 BFH-50192 Weight Stack Decals 2
ITEM NO. PART NUMBER DESCRIPTION QTY
113 BFH-50250 1 1/4" Shoulder Bolt 2
114 BFH-50267 5/16"-18 Nylock (Black) 2
115 BFH-50144 FHSCS 3/8"-16 X 1" 2
116 BFH-50254 HCS 3/8”-16 X 3/4” P5 2
118 BFH-50279 HCS 3/8”-16 X 5" P5 4
119 BFH-50245 FHSCS 5/16"-18 X 1" 2
128 BFH-50188 Snap Hook 4
129 BFH-50211 2" Square Plastic Cap 1
130 BFH-50212 2" x 3" Plastic Cap 2
131 BFH-50215 1 1/2" Square Plastic Cap 6
133 BFH-50227 Cable Strap 5
136 BFH-50238 Pin 2
137 BFH-50239 Snap Ring 2
138 BFH-50244 1/2" Bronze Bushing 8
140 BFH-50248 13/32" Bushing 8
143 BFH-50297 1" Flanged Bushing x 1/2"L 2
144 BFH-50590 Plastic Sleeve 3
145 BFH-50602 1" ID Bearing 14
146 BFH-50604 2" Interior Snap Ring 26
147 BFH-50607 Pull Pin Threaded Cap 2
148 BFH-50608 5" Plastic Sleeve 1
149 BFH-50609 Molded Grip 1" ID 1
150 BFH-50611 2" Round Plastic Cap 3
151 BFH-50612 1 3/4" x 4" Rectangular Cap 4
152 BFH-50614 6" Rubber Grips 2
153 BFH-50618 Mounting Bracket 2
154 BFH-50203 1/2" Curved Pulley Spacer 8
155 BFH-50204 3/8” Curved Washer (Black) 8
181 BFH-50339 Large Flat Leveler 2
182 BFH-50337 Wavy Washer 5
183 BFH-50630 FHSCS 3/8”-16 X 3/4” 2
184 BFH-50631 HCS 3/8”-16 X 1/2” P5 4
186 BFH-50620 BHSCS 3/8”-16 X 3/4” 6
187 BFH-50622 Upholstery Cap 6
ITEM NO. PART NUMBER DESCRIPTION QTY
101 CAB-13021 Fusion Lat Pull to Functional Arm 2
109 CAB-13022 Fusion Weight Stack to Cable Tie Out 1
103 CAB-13024 Fusion Floating Pulley Cable 1
104 CAB-13025 Fusion Leg Extension Cable 1
106 CAB-13026 Fusion Tie Out Cable 1
