www.batcafitness.com 5 Fusion 2 Owner’s Manual
Leg Press Components
Tools Required
 1/2” Wrench
 9/16” Wrench
 9/16” Ratchet
 3/4” Wrench
 3/4” Ratchet
 Allen Wrench Set
 Tape Measure
 Snap Ring Pliers
Leg Press Hardware
Upholstery
Cables
ITEM NO. PART NUMBER DESCRIPTION Qty
102 CAB-13023 Fusion Leg Press Cable 1
ITEM NO. PART NUMBER DESCRIPTION Qty
61 BFH-50119 HCS 3/8"-16 X 1 1/4" P5 2
70 BFH-50121 HCS 3/8"-16 X 2" P5 1
76 BFH-50123 HCS 3/8"-16 X 2 1/2" P5 2
63 BFH-50125 HCS 3/8"-16 X 3" P5 2
69 BFH-50126 HCS 3/8"-16 X 3 1/4" P5 2
82 BFH-50127 HCS 3/8"-16 X 3 1/2" P5 3
83 BFH-50130 HCS 3/8"-16 X 4 1/4" P5 1
84 BFH-50131 HCS 3/8"-16 X 4 1/2" P5 1
85 BFH-50145 FHSCS 3/8"-16 X 2 1/4" 3
56 BFH-50146 3/8" Flat Washer (Black) 34
60 BFH-50147 3/8" Lock Washer (Black) 4
99 BFH-50149 3/8"-16 Jam Nut (Zinc) 3
58 BFH-50157 3/8"-16 Nylock (Black) 22
55 BFH-50165 1" Snap Ring 4
ITEM NO. PART NUMBER DESCRIPTION Qty
8 BFH-50173 3 1/2" Pulley 5
90 BFH-50249 1 3/4 Shoulder Bolt 2
113 BFH-50250 1 1/4" Shoulder Bolt 1
64 BFH-50251 1/2" Flat Washer (Black) 2
98 BFH-50253 Beveled Leveler 1
114 BFH-50267 5/16"-18 Nylock (Black) 1
59 BFH-50270 HCS 3/8"-16 X 5 1/4" P5 4
73 BFH-50285 HCS 3/8"-16 1 3/4" P5 1
75 BFH-50605 3/8" Pulley Spacer 5
89 BFH-50610 1 1/2" Shoulder Bolt 2
92 BFH-50256 1/2” Jam Nut 1
181 BFH-50339 Large Flat Leveler 1
182 BFH-50337 Wavy Washer 2
188 BFH-50338 Sleeve 2
ITEM NO. PART NUMBER DESCRIPTION Qty
166 BFM-10597 Back Seat Frame 1
164 BFM-10598 Bottom Seat Frame 1
157 BFM-10605 Leg Press Frame 1
170 BFM-50252 Four Bar 2
171 BFM-51149 9 1/2" Shaft 1
168 BFM-51150 5 3/4" Shaft 1
159 BFM-51155 2 1/32" Axle 3
160 BFM-51157 3 1/32" Axle 1
180 BFM-51130 Front Pivot 1
ITEM NO. PART NUMBER DESCRIPTION Qty
172 BFL-50128 Foot Plate 1
162 BFL-50219 Bench Frame Plate 2
165 BFM-10106 Chrome Pad Adjustment 1
158 BFM-10575 Leg Press Connector Assembly 1
169 BFM-10590 Foot Plate Pivot 1
167 BFM-10591 Leg Press Pivot Arm 1
163 BFM-10595 Chrome Adjustment 1
161 BFM-10596 6" Telespar 1
ITEM NO. PART NUMBER DESCRIPTION Qty
173 BFU-10117 Large Bottom Pad 1
174 BFU-10120 Back Pad With Lumbar 1
