Batca Fitness Systems 12 LD-4 Owner's Manual
Item # Part # Description Qty
28 BFP-10857 Back Support Tube 1
29 BFP-52149 Anti Deection Plate 1
59 BFP-52374 FHSCS 3/8” x 2 3/4” 2
70 BFH-50146 3/8” Flat Washer 2
71 BFH-50157 3/8” Nylock 2
Step 8:
Make sure all bolts are tightened before moving on
All Flat Washers and Nylocks are 3/8” unless otherwise noted.
