www.batcafitness.com 13 LD-4 Owner’s Manual
Item # Part # Description Qty
41 BFP-52137 Head Pad 1
42 BFP-52136 Back Pad with Lumbar 1
43 BFP-52130 Large Bottom Pad 1
58 BFP-51750 SHCS 3/8” x 2 3/4” 4
61 BFP-51748 SHCS 3/8” x 3 1/4” 2
70 BFH-50146 3/8” Flat Washer 6
72 BFH-50147 3/8” Lock Washer 6
Step 9:
Make sure all bolts are tightened before moving on
All Flat Washers and Nylocks are 3/8” unless otherwise noted.
To Next Page
