Batca Fitness Systems 8 LD-4 Owner's Manual
Item # Part # Description Qty
16 BFP-10865 Leg Ext./Curl J-Brace 1
17 BFP-51863 Anti Deection Plate 1
18 BFP-10948 Adjustment Tube 1
48 BFP-52371 5/16” x 1/2” 2
61 BFP-51748 SHCS 3/8” x 3 1/4” 2
64 BFP-51850 SHCS 3/8” x 5” 2
67 BFH-50204 3/8” Curved Washer 4
70 BFH-50146 3/8” Flat Washer 4
71 BFH-50157 3/8” Nylock 4
Step 4:
All Flat Washers and Nylocks are 3/8” unless otherwise noted.
Anywhere a washer is against the round side of a tube there is to be
a 3/8” CURVED WASHER instead of a 3/8” FLAT WASHER.
Make sure all bolts are tightened before moving on
To Next Page
