DTC DRAWER ASSEMBLY & ADJUSTMENT
Left/Right Adjustment
In/Out Adjustment
Up/Down Adjustment
You can adjust the drawer left or right
by turning the front screw clockwise or
counter clockwise to the desired position.
To adjust the doors up or down, turn the
back screw clockwise or counter clockwise
to the desired position.
You can adjust the drawer front
in or out by pushing or pulling the
leaver at both sides of the bottom
of the drawer.
Press in
Remove Cover
Unclip cover on both sides of drawer
