PARTS IDENTIFICATION
We continually strive to ensure that we provide you with the best possible products, therefore
SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE
1
2
3
4
5
6
7
8
9
10
11
Lights ON/OFF Button
Mode Button
Power Assistance Level Indication
Power UP Button
Charging Socket
Battery Charge Level Indication
Walk Assist (6 Km/h) Button
LCD Information Area
Throttle (Pedalling Only) / Walk Assist
Power ON/OFF Button
Power DOWN Button
1
6
5
2
3
4
7
FITTED AS STANDARD ON:-
OMEGA
ALPHA
SIGMA
QUINTESSENTIAL
LED
CONNECTS TO BIKE
WIRING HARNESS
PRODUCT PART NUMBERS
The following shows the ProMovec part numbers required for each display type and bike model.
Please ensure you select the correct size bracket if fitting a Centre Display
50713
50707-2
50930
50935
50937
50938
Centre LCD Bracket for handlebar diameter 32 mm
Centre LCD Bracket for handlebar diameter 22 mm
LED Display Unit
Centre LCD without Charging Socket (All models except PERDU)
Mini LCD without Charging Socket (All models except PERDU)
Centre LCD with Charging Socket (For PERDU)
