Page 14 For technical questions, please call 1-888-866-5797. Item 63437
SAFETY OPERATION MAINTENANCESETUP
Part Description Qty
1 Chuck 1
2 Protective Lining 1
3 Φ30 Retaining Ring 1
4 Support Patch 1
5 Shock Absorption Ring 1
6 Move Limited Ring 1
7 Insert Block 2
8 Change Plate 1
9 Support Ring Spring 1
10 Support Ring 1
11 Move Limited Ring 1
12 Φ6.5 Steel Ball 8
13 Hex. Socket Bolt
M8×30 (12.9)
4
13A Φ8 Spring Washer 4
14 Flange Cover 1
15 O-Ring Ø63.5×Φ2.6 1
16 Hammer Rod Sleeve 1
17 Fluorin O Ring
Φ31.6×Φ2.6
1
18 Φ41 Retaining Ring 2
19 Oil Seal Ring
Φ32×Φ42×7
1
20 Impact Pin 1
21 Fluorin O Ring
Ø22×Φ11
1
22 Control Plate 1
23 Fixed Distance Sleeve 1
24 O-Ring Ø35×Φ3 1
25 Impact Block 1
26 Fluorin O Ring
Ø30.4×Φ5
2
27 Cover 1
28 Control Sleeve 1
29 Control Sleeve Spring 1
30 Cylinder 1
31 Piston Pin Φ10×38 1
32 Piston 1
33 Connecting Rod Ass’y 1
34 Impact Body 1
Part Description Qty
35 Tapping Screw
St6.3x32
4
36 Oil Tank Cover 1
37 Rubber Washer
Ф31хф25х1.2
1
38 Felt Ring 1
39 Hex .Socket
Bolt m5×12
4
40 Shell Cover 1
41 O-Ring Ø79×Φ2.8 1
42 Eccentric Gear
Subassembly
1
43 Boring Washer 2
44 Needle Bearing
Rmao16×22×16
2
45 Needle Ferrule 1
46 Needle Bearing
Nk20×28×13
1
47 Seal Ring
Subassembly
2
48 Housing 1
49 Cord Clip 1
50 St4.2×18 Tapping
Screw
4
52 Main Handle Cover 1
54 Indicator Light 1
55 Main Handle 1
56 St5.5×45 Tapping
Screw
2
58 Cord Sleeve 1
59 Cord 1
61 Rivet 2
62 Stator 110-120V 1
63 St4.8×58 Tapping
Screw
2
64 Carbon Brush Bracket 1
65 Helical Spring 2
66 Metal Contact Plate 1
67 Tapping Screw
St3.5x16
7
68 Metal Insert 2
Part Description Qty
69 Carbon Brush 2
70 Carbon Brush Wire 2
71 Screw Seal Ring 1
72 Armature 110-120V 1
73 Bearing Sleeve 1
74 6200 2Rs Ball Bearing 1
74A Φ10 Retaining Ring 1
75 O-Ring Φ30×Φ2 1
76 Screw Ring 1
77 Protected Cover 1
78 Bearing Cover 1
79 Tapping Screw
St5.5x25
8
80 Disk With Gap 2
81 Clamping 2
82 Fixed Belt 1
83 hex Head Bolt M8×130 1
84 Side Handle 1
85 Function Knob 1
86 Nut M8 (Thickness
6.4Mm)
1
87 Function Knob Cover 1
88 10Mm Hex Bar Wrench 1
89 Dual Screw Driver 1
91 Oil Bottle Ø35×135 1
92 Fixed Platen 1
93 Main Handle Seat 1
94 Shock Absorption
Jacket
1
95 Shock Absorption
Ferrule
2
96 Shock Absorption
Spring
1
97 Spring Rack 1
98 Cross Recessed
Pan Head Screws
M6×50 (Φ18)
2
99 O-Ring Ø16×Φ3 2
101 Speed Adjuster 1
102 Switch 1
Parts List and Diagram
