24000CVF/SVF Valves
June 2017
11
Table 2. Plug and Seat Ring for NPS 1/2, 3/4, and 1 Valves (continued)
KEY
NO.
DESCRIPTION PLUG TYPE PLUG NO.
ORIFICE DIAMETER
mm (Inch)
C
v
(2)
VALVE SIZE
DN 15 (NPS 1/2) DN 20 (NPS 3/4) DN 25 (NPS 1)
4*
Plug & Stem
Assy
PTFE Seat (Linear) 677
9.5 (0.375)
0.1 24660-101-677
0.2 24625-101-677
0.5 24617-101-677
1.0 24631-101-677
2.8 24656-101-677 ---
3.3 --- --- 24656-101-677
20.6 (0.8125)
3.4 24010-1-101-677 ---
5.1 --- --- 24010-1-101-677
Metal Seat (Linear)
648
(S41600)
6.3 (0.25)
0.5
(1)
GE46398X052 GE46398X092
1.0
(1)
GE46397X052 ---
1.4
(1)
--- --- GE46397X092
9.5 (0.375)
1.6 24669-1-101-648 ---
1.7 --- --- 24669-1-101-648
2.9 24671-2-101-648 ---
3.3 --- --- 24671-2-101-648
20.6 (0.8125)
3.7 24757-5-101-648 ---
4.6 --- --- 24757-5-101-648
6.1 24717-3-101-648 --- ---
9.8 --- 24717-3-101-648 ---
11 --- --- 24717-3-101-648
26.9 (1.0625) 13 --- --- 24791-1-101-648
Metal Seat (Linear) 688
6.3 (0.25)
0.5
(1)
GE46396X052 GE46396X092
1.0
(1)
GE46395X062 ---
1.4
(1)
--- --- GE46395X102
9.5 (0.375)
1.6 24669-101-688 ---
1.7 --- --- 24669-101-688
2.9 24671-101-688 ---
3.3 --- --- 24671-101-688
20.6 (0.8125)
3.7 24757-101-688 ---
4.6 --- --- 24757-101-688
6.1 24717-101-688 --- ---
9.8 --- 24717-101-688 ---
11 --- --- 24717-101-688
26.9 (1.0625) 13 --- --- 24791-101-688
2* Seat Ring
9.5 (0.375) Orifice Diameter, S31600 007635-002-163 24000-342
20.6 (0.8125) Orifice Diameter, S31600 007635-005-163 24000-343
26.9 (1.0625) Orifice Diameter, S31600 --- --- 24000-344
9.5 (0.375) Orifice Diameter, S41600 007635-002-416 24000-342-1
20.6 (0.8125) Orifice Diameter, S41600 007635-005-416 24000-343-1
26.9 (1.0625) Orifice Diameter, S41600 --- --- 24000-344-1
1. Matching seat ring (key 2) is furnished with replacement plug orders.
2. K
v
equals (0.86)*(C
v
)
