Baumann 24000CVF User Manual

Instruction Manual
D103360X012
24000CVF/SVF Valves
June 2017
19
Table 11. Baumann Valve Dimensions
VALVE SIZE
A -- FACE-to-FACE B -- BONNET
CL150 CL300 PN 10-40 Standard Single Extension Bellows
DN NPS mm Inch mm Inch mm Inch mm Inch mm Inch mm Inch
15 1/2 184 7.25 190 7.50 130 5.11 79 3.1 216 8.5 226 8.9
20 3/4 184 7.25 194 7.62 150 5.90 79 3.1 216 8.5 226 8.9
25 1 184 7.25 197 7.75 160 6.30 84 3.3 221 8.7 229 9.0
40 1-1/2 222 8.75 235 9.25 200 7.87 96 3.8 234 9.2 229 9.0
50 2 254 10.0 267 10.5 230 9.06 107 4.2 244 9.6 234 9.2
Table 12. Baumann Valve Assembly Weights
VALVE SIZE
WEIGHTS
CL150 CL300 PN 10-40
DN NPS kg lb kg lb kg lb
15 1/2 3.0 6.6 3.5 7.7 3.3 7.3
20 3/4 3.1 6.9 4.2 9.3 3.4 7.6
25 1 5.1 11.3 5.9 13.1 5.7 12.6
40 1-1/2 7.9 17.5 10.7 23.5 8.8 19.5
50 2 13.4 29.5 15.0 33.1 14.4 31.9
Table 13. Baumann Actuator Weights
ACTUATOR
WEIGHTS
kg lbs
32 4.5 10
54 11.3 25
70 15.4 34
MV1020
(1)
10 22
VA1020
(1)
14 30
NV24-MFT (non spring return)
(1)
1.5 3.3
NVF24-MFT or NVF24-MFT-E (spring
return)
(1)
1.8 4
1. Electric actuators, reference electric actuator bulletin for more details (52.1:ECV, D103347X012)
