Baumann 24000CVF User Manual

Instruction Manual
D103360X012
24000CVF/SVF Valves
June 2017
9
Table 1. Baumann 24000CVF/SVF Common Parts
KEY
NO.
QTY DESCRIPTION
VALVE SIZE
DN15
(NPS 1/2)
DN20
(NPS 3/4)
DN25
(NPS 1)
DN40
(NPS1-1/2)
DN50
(NPS 2)
1 1
Valve Body, Carbon Steel, CL150 24000-165 24000-265 24000-365 24000-565 24000-665
Valve Body, Carbon Steel, CL300 24000-167 24000-267 24000-367 24000-567 24000-667
Valve Body, Carbon Steel, PN 10-40 24000-169 24000-269 24000-369 24000-569 24000-669
Valve Body, Stainless Steel, CL150 24000-115 24000-215 24000-315 24000-515 24000-615
Valve Body, Stainless Steel, CL300 24000-117 24000-217 24000-317 24000-517 24000-617
Valve Body, Stainless Steel, PN 10-40 24000-119 24000-219 24000-319 24000-519 24000-619
8 1
Bonnet, Standard for Carbon Steel 24000-163 24000-363 24000-563 24000-663
Bonnet, Standard for Stainless Steel 24000-123 24000-323 24000-523 24000-623
Bonnet, Single Ext
(2)
24000-123-1 24000-323-1 24000-523-1 24000-623-1
Bonnet, Double Ext
(2)
24000-123-2 24000-323-2 24000-523-2 24000-623-2
Bonnet, Triple Ext
(2)
24000-123-3 24000-323-3 24000-523-3 24000-623-3
Bonnet, NOLEEK Bellows
(2)
24000-130 24000-330 24000-530 24000-630
8a 1 Guide Bushing
(1)
24000-124 (24000CVF ONLY)
9 1 Drive Nut (Yoke) 011757-003-153
10 1 Packing Follower 24490-1
11 4 Stud 24000-127 24000-126
12 4 Nut 25705 25717-1
14* 1 V-Ring Packing Set (standard) 24494T001 (See page 13 for additional packing options)
27 2 Locknuts 971514-002-250
49* 1 Valve Body Gasket 24000-133 24000-133 24000-333 24000-533 24000-633
58 1 Travel Indicator 24299
1. Guide bushing is applicable to 24000CVF valve ONLY.
2. Extension bonnets and NOLEEK bellows bonnets are not available with 24000CVF carbon steel valves.
*Recommended spare parts

Baumann 24000CVF Specifications

General

Brand	Baumann
Model	24000CVF
Category	Control Unit
Language	English
