15
HOB APERTURE DIMENSIONS
MODEL A B C D E
AS6.2
685 510 665 490 50
B13
580 510 560 490 40
B14
580 510 560 490 40
BH14
580 510 560 490 40
B15
580 510 560 490 50
BF16
770 510 750 490 50
BF15
580 510 560 490 40
BF16
770 510 750 490 50
